Standard series PART# Explanation
Specification
(RF Rotary joints) Specifications
Mechanical data
Parameter
Value
Parameter
Value
Frquency
0~3GHz
Working Life
50Million Revs.
Rated Power
5W
Rotating Speed
150RPM
VSWR
<1.3
Working Temp.
-30℃~80℃
Insertion Loss
0.3db
Operating Humidity
0~85% RH
VSWR Ripple
<0.05
Contact Material
Gold-Gold
Insertion Loss Ripple
0.05db
Housing Material
Aluminium Alloy
Connector Types
Exit coaxial-cable directly
Torque
0.1N.m;+0.03/6ring
Characteristic Impedance
50Ω/75Ω
Protection grade
IP51
Electrical data
Parameter
Value
Power
Signal
Rated Voltage
0~440VAC/VDC
0~240VAC/VDC
Insulation Res
≥1000MΩ/500VDC
≥1000MΩ/500VDC
Lead Wires
AWG16#Teflon
AWG22#Teflon
Lead Length
Standard 300mm
Dielectric Strength
500VAC@50Hz，60s
Res Noise
<0.01Ω
Part List
Dimension
Installing
Options
Customized
Case-Study
Price
MHF107 series RF rotary joint part list
Part#
RF Channel
Frquency
10A
Signal/5A
Length(mm)
MHF107-S06
1
DC-3GHz
0
6
25.4
MHF107-S12
1
DC-3GHz
0
12
39.2
MHF107-S18
1
DC-3GHz
0
18
53
MHF107-S24
1
DC-3GHz
0
24
66.8
Rings and current can be customized
