Housing
Metric
Housing
Short-body
Thread size
M12 x 1
Diameter
Ø 12 mm
Sensing range Sn
0 mm … 60 mm 1)
Safe sensing range Sa
48.6 mm
Magnetic sensitivity
1 mT
Switching frequency
1,000 Hz
Connection type
Cable, 3-wire, 2 m
Switching output
PNP
Output function
NC
Electrical wiring
DC 3-wire
Magnetic alignment
Axial
Enclosure rating
IP67 2)
Items supplied
Mounting nut, brass, nickel-plated (2x)
1) Sensing range based on installation in non-magnetic material using Magnet MAG-3010-B (M4.0).
2) According to EN 60529.
Technical drawings
Installation note
Connection diagram Cd-003
Sensing range
Dimensional drawing MM12, cable, short-body housing
