Cảm biến sợi quang Sick WLL80I-1HT6Y4DZA71Z1Z1
Device type
Fiber-optic amplifier
Device type detail
Stand-alone
Functional principle detail
Depending on the optical fiber cable used
Sensing range max.
Depending on the optical fiber cable used
Emitted beam
Light source
LED
Type of light
Infrared light
Key LED figures
Normative reference
EN 62471:2008-09 | IEC 62471:2006, modified
LED risk group marking
Free group
Wave length
1,450 nm
Average service life
100,000 h at Ta = +25 °C
Adjustment
IO-Link
For configuring the sensor parameters and Smart Task functions
Wire/pin
For deactivating the sender and executing the test logic/for setting the sensing range/for resetting the counter
Display + operating buttons
For configuring the sensor parameters
Indication
LED green
Operating indicator
Static on: power on
Flashing: IO-Link mode
LED yellow 1
Status of switching output 1
Permanently on: Switching output 1 active
Permanently off: Switching output 1 not active
Flashing: Executing teach-in/teach-in error
LED yellow 2
Status of switching output 2
Permanently on: Switching output 2 active
Permanently off: Switching output 2 not active
Flashing: Executing teach-in/teach-in error
Display
Display of sensor functions
OLED display
Items supplied
BEF-WLL180 mounting bracket
Technical drawings
display and adjustment elements
Connection diagram Cd-530
Dimensional drawing
